Intel Core i7 7500U Mini PC With Linux Gigabit Ethernet Supports HD Display
Intel Core i7-7500U Mini PC Description:
This mini host equipped with Intel Core i7-7500U processor brings you a powerful performance experience in a palm-sized body. The dual-core four-thread design with 3.5GHz turbo acceleration can easily handle multi-tasking and complex calculations. The 14nm process technology and 15W low power consumption characteristics ensure stable operation while greatly reducing energy consumption.
Compatible with the full range of Windows 8/10 and mainstream operating systems such as Linux/Ubuntu/CentOS, providing flexible deployment solutions for developers, educational institutions and corporate users.
The compact body has a built-in efficient heat dissipation system to ensure long-term stable operation; it supports wall-mounted installation to save desktop space. It is suitable for smart office, digital signage, home theater, industrial control and other scenarios, achieving great results with a small body.
Intel Core i7-7500U Mini PC Details:
| CPU | Intel Core i7-7500U 2 Cores 4 Threads Processor, 3.50GHz Max Turbo Frequency, 4MB Cache, 14nm Lithography, 15W TDP |
| GPU | Intel® HD Graphics 620 |
| LAN | 1*Gigabit Ethernet, 10/100/1000/ Mbps Realtek 8111F, Supports Wake-On-LAN |
| AUD | Realtek ALC662 audio control chip, supports dual-channel, stereo, Line out |
| Display | 1*VGA, 1*HDMI, Support Dual Screen Synchronous Or Asynchronous Display |
| RAM | 1*DDR3L SODIMM RAM, 1333/1600MHz, Max Up To 16GB |
| Stroage | 1*Full-height mSATA SSD |
| Extension | 1*half-height Mini PCIe |
| Power | 1*DC-IN 5.5*2.5, DC 12V 5A/36W (AC TO DC, 100~240V) |
| I/O Interface | 4*USB3.0, 2*USB2.0, 1*Power Switch, 1*Gigabit Ethernet, 1*VGA, 1*HDMI, 1*DC, 1*MIC, 1*SPK |
| Operating System | Windows 8, Windows 10, Linux, Ubuntu, CentOS, etc. |
| Dimension/Weight | 136MM * 128MM * 42MM/ About 1.0kg |
| Installation | Desktop/ Wall Mount/ VESA |
| Suitable Environment | Operating Temperature: -20℃ to +65℃, Storage Temperature: -20℃ to +75℃, Relative Humidity: 5%~95% (non-condensing) |
Intel Core i7-7500U Mini PC Processor Graphics:
With Intel HD Graphics 620 core display, it smoothly supports 4K ultra-clear video playback and light graphics processing. The UHD 620 high-definition integrated graphics card of the seventh-generation Core host supports the current popular medium-sized online games, and office and daily use are not affected.
Intel Core i7-7500U Mini PC Hard Disk And Memory:
This mini pc adopts a flexible memory expansion design, equipped with 1×DDR3L SODIMM slot, and supports 1333/1600MHz high-speed memory. Whether it is multitasking, virtualization applications or graphics rendering, it can be smoothly operated through dual-channel expansion, easily meeting the needs of enterprise-level office and creative design.
In terms of storage, it is equipped with 1×Full-height mSATA SSD interface, which supports high-speed solid-state drive expansion. The mSATA protocol provides 6Gbps transmission bandwidth, combined with the low latency characteristics of SSD, greatly improving the system startup speed and data throughput efficiency. Users can flexibly choose large-capacity storage solutions such as 512GB/1TB according to their needs to meet the needs of data-intensive applications.
Intel Core i7-7500U Mini PC Application:
The mini desktop computer has strong expandability and is suitable for various life scenarios, whether it is home office or gaming entertainment. It can also be connected to the living room TV, projector, car, printer, etc.
Intel Core i7-7500U Mini PC Interface View:
Rich interface configuration meets diverse expansion needs: 1×VGA and 1×HDMI dual display output, supports synchronous and asynchronous dual-screen display, whether it is multi-screen office or immersive entertainment, it can be easily achieved.
